Fuse Link HRC Offset Bolted Tags BS88 6A 550V AC
£5.64
Part Number: 2500522208 MPN: NIT6 Product Type: Industrial Fuses
Description
Part Number: 2500522208 MPN: NIT6 Product Type: Industrial Fuses
Product Details
NIT Red Spot industrial offset bolted tags fuse links are specifically designed for the protection of general industrial applications, e.g. power distribution, cable protection.
- BS reference: A1
- 1: 1: 6 selective coordination ratio between “minor” and “major” fuse
- gM characteristics for motor protection applications
- Power loss values within the limits of IEC 60269
- Compatible with Camaster 32A compact CM32FC and Red Spot 20A RS20
- Pre-arching: 22
- Total at rated voltage: 150
- 44mm fixing centre
Technical Specifications
HRC fuse |
|
| Current type | AC/DC |
|---|---|
| Colour code | None |
| Type of fuse status indicator | None |
| Fuse construction type according to IEC 60269 | A1 |
| Rated current | 6 A |
| Breaking capacity | 80 kA |
|---|---|
| Rated voltage AC | 550 V |
| Centre-to-centre distance of connections | 44.5 mm |
| Power loss at rated current | 1.8 W |
| Rated voltage DC | 250 V |
