100A 300mA TYPE AC 4P RCD
£255.93
Part Number: 2500055170 MPN: WRL100/4 Product Type: Residual Current Devices
Description
Part Number: 2500055170 MPN: WRL100/4 Product Type: Residual Current Devices
Product Details
A residual current circuit breaker; provide valuable additional protection to almost any type of installation by detecting earth fault current below the level sensed by traditional overcurrent device such as fuses of miniature circuit breaker. The RCD emp
- Four Pole RCCB
- 100A 300mA
- Type AC
- For use with Wylex NH distribution boards
- For incoming options, can be used with NH4PINKIT connection kit
- Contact position indication on the dolly handle
- Terminal Capacity 35mm
Technical Specifications
Residual current circuit breaker (RCCB) |
|
| Leakage current type | AC |
|---|---|
| Degree of protection (IP rating) | IP20 |
| Frequency | 1/2 inch |
| Mounting method | Symmetric |
| Width in number of modular spacings | 4 |
| Rated impulse-withstand voltage (Uimp) | 4 kV |
| Rated insulation voltage Ui | 400 V |
| Rated current | 100 A |
|---|---|
| Number of poles | 4 |
| Rated fault current | 0.3 A |
| Rated voltage | 415 V |
| With interlocking device | No |
| Selective protection | No |
| Additional equipment possible | No |
