Miniature circuit breaker (MCB) 25 A 1p characteristic: B
£19.47
Part Number: 2500330760 MPN: EMBH125 Product Type: Miniature Circuit Breakers
Description
Part Number: 2500330760 MPN: EMBH125 Product Type: Miniature Circuit Breakers
Product Details
EM miniature circuit-breaker, 1 pole, trip type: B, rated operational current In: 25 A, rated switching capacity according to IEC/EN 60947-2: 15 kA, rated switching capacity according to IEC/EN 60898-1: 10 kA, switchgear for residential and non-residential applications
- Breaking Capacity: 10/15kA
- Current Rating: 25A
- Height: 80mm
- Number of Poles: 1
- Range: Memshield 3
- Width: 18mm
- Capacity: 10/15kA
- Depth: 60mm
Technical Specifications
Miniature circuit breaker (MCB) |
|
| Rated short-circuit breaking capacity Icn EN 60898 at 230 V | 10 kA |
|---|---|
| Explosion-proof | No |
| Additional equipment possible | Yes |
| Concurrently switching N-neutral | No |
| Flush-mounted installation | No |
| Connectable conductor cross section multi-wired | 1 – 25 mm² |
| Connectable conductor cross section solid-core | 1 – 25 mm² |
| Ambient temperature during operating | -25 – 75 °C |
| Frequency | 50 – 60 Hz |
| Rated insulation voltage Ui | 440 V |
| Rated voltage | 230 V |
| Rated short-circuit breaking capacity Icn EN 60898 at 400 V | 10 kA |
| Width in number of modular spacings | 1 |
| Tripping characteristic (type/curve) | B |
|---|---|
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V | 15 kA |
| Rated current | 25 A |
| Number of poles (total) | 1 |
| Current limiting class | 3 |
| Over voltage category | 3 |
| Number of protected poles | 1 |
| Recess depth | 70.5 mm |
| Rated impulse-withstand voltage (Uimp) | 4 kV |
| Pollution degree | 2 |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V | 15 kA |
| Degree of protection (IP rating) | IP20 |
| Voltage type | AC |
