Distribution Board Triple Pole+Neutral Smart Meter+200A SD 200A Incomer Fitted EBMSL862MPMB
£1,997.36
Part Number: 2500779789 MPN: EBMSL862MPMB Product Type: Distribution Boards 3 Phase
Description
Part Number: 2500779789 MPN: EBMSL862MPMB Product Type: Distribution Boards 3 Phase
Product Details
Split metered power and lighting board – 200A TPN, type B incl. combined pulsed and modbus meter
- Meter has both pulsed and Modbus outputs as standard
- Fitted with door lock as standard
- Single phasing kit included to be used if required
- Adequate integral cabling space means that no extension box is required
- Includes factory fitted 200A switch disconnector and two channel meter
Technical Specifications
Meter cabinet equipped |
|
| Recess height | 1236 mm |
|---|---|
| With mounting plate | No |
| Number of meter cabinets | 1 |
| Height | 1236 mm |
| Number of distributor rows | 1 |
| Width | 440 mm |
| Rated current | 0 A |
| Recess width | 440 mm |
| Depth | 130 mm |
| Mounting method | Surface mounted |
|---|---|
| Recess depth | 130 mm |
| Number of fields | 1 |
| Number of tariff control panels | 0 |
| Material | Steel plate |
| Degree of protection (IP rating) | IP3X |
| Lower connection space | With clamps |
| Model | 1-story |
