Description
Part Number: 2500331189 MPN: EMCH316 Product Type: Miniature Circuit Breakers
Product Details
EM miniature circuit-breaker, 3 pole, trip type: C, rated operational current In: 16 A, rated switching capacity according to IEC/EN 60947-2: 15 kA, rated switching capacity according to IEC/EN 60898-1: 10 kA, switchgear for residential and non-residential applications
- DIN rail mountable
- Suitable for use with both pin and comb type busbar systems
- Suites RCBOs, RCCBs and isolators
- Positive contact is flag indicator
- Operating temperature: -25 to 55 °C
- Impulse withstand voltage: 5kV
- Energy limiting class 3
- Certified by KEMA
- Designed & tested in accordance with IEC 60898 & IEC 60947-2
Technical Specifications
Miniature circuit breaker (MCB) |
|
Rated short-circuit breaking capacity Icn EN 60898 at 400 V | 10 kA |
---|---|
Additional equipment possible | Yes |
Flush-mounted installation | Yes |
Concurrently switching N-neutral | No |
Explosion-proof | No |
Ambient temperature during operating | -25 – 55 °C |
Connectable conductor cross section multi-wired | 1 – 25 mm² |
Connectable conductor cross section solid-core | 1 – 25 mm² |
Frequency | 50 – 60 Hz |
Rated impulse-withstand voltage (Uimp) | 4 kV |
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V | 0 kA |
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V | 0 kA |
Rated short-circuit breaking capacity Icn EN 60898 at 230 V | 10 kA |
Voltage type | AC |
---|---|
Number of poles (total) | 3 |
Width in number of modular spacings | 3 |
Pollution degree | 2 |
Over voltage category | 3 |
Current limiting class | 3 |
Rated insulation voltage Ui | 440 V |
Number of protected poles | 3 |
Rated voltage | 240 V |
Recess depth | 70.5 mm |
Rated current | 16 A |
Degree of protection (IP rating) | IP20 |
Tripping characteristic (type/curve) | C |
