6491X 10.0mm² Blue PVC Basec Cable 1-Core

£2.57

Part Number: 2500019586     MPN: 20147003       Product Type: 6491 (Singles)
Categories: , ,

Description

Part Number: 2500019586     MPN: 20147003       Product Type: 6491 (Singles)

Product Details

Prysmian 6491X is a single core, low voltage wiring cable designed for installation within conduit, trunking or inside fixed protected environments

  • · Installation in surface mounted or embedded conduits, or similar closed systems and for fixed protected installation
  • · Green/Yellow for use as earth can be installed without mechanical protection.
  • · Length in metres: 100
  • · No. of cores: 1
  • · Product Packaging: Reel
  • · Material: PVC
  • · Standard: BS EN 50525-2-31

Technical Specifications

Power cable < 1 kV, for fixed installations
Number of cores 1
Low temperature resistant according to EN 60811-504+505+506 No
Oil resistant according to IEC 60811-404 No
Permitted cable outer temperature during assembling/handling 0 – 60 °C
Min. permitted bending radius, stationary application/permanent installation 38 mm
Outer diameter approx. 6.3 mm
Nominal voltage U 750 V
Nominal voltage U0 450 V
Max. conductor temperature 70 °C



Conductor category Class 2 = stranded
Core insulation material Polyvinyl chloride (PVC)
Nominal cross sectional area of conductor 10 mm²
Core identification Colour
Sheath colour Green/yellow
Core colour Blue
Conductor material Copper
Conductor surface Bare
