MCB Double Pole Type C 16A 10/15Ka 36 x 80 x 75mm

£110.90

Part Number: 2500330909                MPN: EMCH216                Product Type: Miniature Circuit Breakers

Description

Part Number: 2500330909                MPN: EMCH216                Product Type: Miniature Circuit Breakers

Product Details

EM miniature circuit-breaker, 2 pole, trip type: C, rated operational current In: 16 A, rated switching capacity according to IEC/EN 60947-2: 15 kA, rated switching capacity according to IEC/EN 60898-1: 10 kA, switchgear for residential and non-residential applications

  • DIN rail mountable
  • Suitable for use with both pin and comb type busbar systems
  • Suites RCBOs, RCCBs and isolators
  • Positive contact is flag indicator
  • Operating temperature: -25 to 55 °C
  • Impulse withstand voltage: 5kV
  • Energy limiting class 3
  • Certified by KEMA
  • Designed & tested in accordance with IEC 60898 & IEC 60947-2

Technical Specifications

Miniature circuit breaker (MCB)
Width in number of modular spacings 2
Additional equipment possible Yes
Flush-mounted installation No
Concurrently switching N-neutral No
Explosion-proof No
Ambient temperature during operating -25 – 75 °C
Connectable conductor cross section multi-wired 1 – 25 mm²
Frequency 50 – 60 Hz
Connectable conductor cross section solid-core 1 – 25 mm²
Rated impulse-withstand voltage (Uimp) 4 kV
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V 15 kA
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V 15 kA
Rated short-circuit breaking capacity Icn EN 60898 at 230 V 10 kA



Voltage type AC
Number of poles (total) 2
Rated short-circuit breaking capacity Icn EN 60898 at 400 V 10 kA
Pollution degree 2
Rated insulation voltage Ui 440 V
Over voltage category 3
Current limiting class 3
Number of protected poles 2
Rated voltage 400 V
Rated current 16 A
Recess depth 70.5 mm
Tripping characteristic (type/curve) C
Degree of protection (IP rating) IP20
